Question 1

How will the methyl carbon appear in the proton off-resonance decoupled 13C spectrum of toluene?

Accepted Answer

A)  Singlet
B)  Doublet
C)  Triplet
D)  Quartet
E)  Quintet
A)  Singlet
B)  Doublet
C)  Triplet
D)  Quartet
E)  Quintet

Question 2

Which one of the following best represents the predicted approximate chemical shift and coupling for the hydrogen(s)indicated with the arrow?

Accepted Answer

A)  1.00 ppm,singlet
B)  2.10 ppm,singlet
C)  2.10 ppm,quartet
D)  3.00 ppm,singlet
E)  2.10 ppm,triplet
A)  1.00 ppm,singlet
B)  2.10 ppm,singlet
C)  2.10 ppm,quartet
D)  3.00 ppm,singlet
E)  2.10 ppm,triplet

Question 3

In mass spectrometry,the most intense peak is assigned an intensity of 100%,and is referred to as the ______________.

Accepted Answer

The answer of In mass spectrometry,the most intense peak is...

Question 4

The 1H NMR spectrum of which of the compounds below,all of formula C7H12O2,would consist of a singlet,a doublet and a triplet only?

Accepted Answer

A)  I
B)  II
C)  III
D)  IV
E)  V
A)  I
B)  II
C)  III
D)  IV
E)  V

Question 5

What is the structure of the compound in the following 1H-NMR spectrum with the molecular formula C5H10O? The IR spectrum does not show any characteristic stretches around 1700 cm-1.Relative integration is shown.

Accepted Answer

A)

B)

C)

D)

E)

A)

B)

C)

D)

E)

Question 6

Which proton(s)of the compound below would appear as a doublet in the 1H NMR spectrum?

Accepted Answer

A)  The protons on carbon I
B)  The protons on carbon II
C)  The protons on carbon III
D)  The protons on carbon IV
E)  The protons on carbon V
A)  The protons on carbon I
B)  The protons on carbon II
C)  The protons on carbon III
D)  The protons on carbon IV
E)  The protons on carbon V

Question 7

What is the structure of the compound in the following 1H-NMR spectrum with the molecular formula C4H7Br? Relative integration is shown.

Accepted Answer

A)

B)

C)

D)

E)

A)

B)

C)

D)

E)

Question 8

Select the structure of a compound C6H14 with a base peak at m/z 43.

Accepted Answer

A)  CH3CH2CH2CH2CH2CH3
B)  (CH3CH2)2CHCH3
C)  (CH3)3CCH2CH3
D)  (CH3)2CHCH(CH3)2
E)  None of these
A)  CH3CH2CH2CH2CH2CH3
B)  (CH3CH2)2CHCH3
C)  (CH3)3CCH2CH3
D)  (CH3)2CHCH(CH3)2
E)  None of these

Question 9

Which one of the following best represents the predicted approximate chemical shift and coupling for the hydrogen(s)indicated with the arrow?

Accepted Answer

A)  5.40 ppm,doublet
B)  1.00 ppm,multiplet
C)  2.00 ppm,doublet
D)  1.00 ppm,doublet
E)  5.40 ppm,multiplet
A)  5.40 ppm,doublet
B)  1.00 ppm,multiplet
C)  2.00 ppm,doublet
D)  1.00 ppm,doublet
E)  5.40 ppm,multiplet

Question 10

What is the structure of the compound in the following 1H-NMR spectrum with the molecular formula C9H10O2? Relative integration is shown.

Accepted Answer

A)

B)

C)

D)

E)

A)

B)

C)

D)

E)

Question 11

A compound C4H9Br gave the following 1H NMR spectrum: triplet,$\delta$ 1.0 (3H);doublet,$\delta$  1.7;multiplet,$\delta$ 1.8;multiplet,$\delta$ 4.1 (1H)
Which is a reasonable structure for the compound?

Accepted Answer

A)  CH3CH2CHBrCH3
B)  CH3CH2CH2CH2Br
C)  (CH3)2CHCH2Br
D)  (CH3)3CBr
A)  CH3CH2CHBrCH3
B)  CH3CH2CH2CH2Br
C)  (CH3)2CHCH2Br
D)  (CH3)3CBr

Question 12

What is the structure of the compound in the following 1H-NMR spectrum with the molecular formula C8H15ClO3,which shows a characteristic stretch in the IR around 1750 cm-1 but not around 3500 cm-1,and a characteristic peak at 173 ppm in the 13C-NMR? Relative integration is shown.

Accepted Answer

A)

B)

C)

D)

E)

A)

B)

C)

D)

E)

Question 13

What is the structure of the compound in the following 1H-NMR spectrum with the molecular formula C9H12O? Relative integration is shown.

Accepted Answer

A)

B)

C)

D)

E)

A)

B)

C)

D)

E)

Question 14

How many 1H NMR signals would trans-1,2-dichlorocyclopropane give?

Accepted Answer

A)  1
B)  2
C)  3
D)  4
E)  5
A)  1
B)  2
C)  3
D)  4
E)  5

Question 15

How many 1H NMR signals would cis-1,2-dichlorocyclopropane give?

Accepted Answer

A)  1
B)  2
C)  3
D)  4
E)  5
A)  1
B)  2
C)  3
D)  4
E)  5

Question 16

"NMR" stands for _______________________.

Accepted Answer

The answer of "NMR" stands for _______________________....

Question 17

How many chemically distinct 1H NMR signals are there in the following compound?

Accepted Answer

A)  1
B)  2
C)  3
D)  4
E)  5
A)  1
B)  2
C)  3
D)  4
E)  5

Question 18

What is the structure of the compound in the following 1H-NMR spectrum with the molecular formula C6H12? Relative integration is shown.

Accepted Answer

A)

B)

C)

D)

E)

A)

B)

C)

D)

E)

Question 19

Which one of the following best represents the predicted approximate chemical shift and coupling for the hydrogen(s)indicated with the arrow?

Accepted Answer

A)  3.00 ppm,doublet
B)  3.00 ppm,triplet
C)  5.00 ppm,triplet
D)  1.00 ppm,doublet
E)  5.40 ppm,multiplet
A)  3.00 ppm,doublet
B)  3.00 ppm,triplet
C)  5.00 ppm,triplet
D)  1.00 ppm,doublet
E)  5.40 ppm,multiplet

Question 20

Which one of the following best represents the predicted approximate chemical shift and coupling for the hydrogen(s)indicated with the arrow?

Accepted Answer

A)  1.00 ppm,quartet
B)  2.40 ppm,singlet
C)  2.40 ppm,quartet
D)  3.00 ppm,quartet
E)  1.00 ppm,triplet
A)  1.00 ppm,quartet
B)  2.40 ppm,singlet
C)  2.40 ppm,quartet
D)  3.00 ppm,quartet
E)  1.00 ppm,triplet
